Jet processing method for making clean-label chocolate milk

Fat-free chocolate milk processed with high-pressure jet technology exhibits enhanced viscosity, stabilising cocoa particles in the fluid and eliminating the need for adding a controversial emulsifier.

That’s the conclusion of a team of Penn State researchers, whose study suggests that the new technology can preclude the use of carrageenan in chocolate milk. The widely used food additive — which helps keep the liquid smooth and well-mixed even after days sitting on a store shelf — is not desired for clean-label or organic chocolate milk.

Although the U.S. Food and Drug Administration has approved the use of carrageenan, concerns about its safety remain, according to team leader Federico Harte, professor of food science. He noted that some scientists believe that the additive — a compound extracted from red seaweed — can cause inflammation and digestive problems such as bloating and irritable bowel disease. As a result, the additive is banned in infant formula in the European Union.

“This research is not about being against carrageenan — it’s about consumers wanting clean food labels with only ingredients they recognise,” he said. “And carrageenan definitely is not something they want in chocolate milk. We know that USDA has considered banning it for organic chocolate milks. Our results indicate that would be possible.”

In the study, researchers thermally treated fat-free chocolate milk formulations containing skim milk, cocoa powder and sugar and then processed them using high-pressure jet technology from 125 to 500 megapascals. The viscosity, flow properties and stability of chocolate milks treated with high-pressure jets were compared with chocolate milks that did not undergo high-pressure jet processing, prepared both with and without adding carrageenan.

As expected, carrageenan-free chocolate milk exhibited immediate phase separation of the cocoa powder, whereas formulations containing carrageenan were stable for 14 days, with cocoa particles not dropping out of suspension. However, the researchers observed increased stability with increasing jet processing pressure, with maximum stability achieved when chocolate milk was processed at 500 megapascals.

“We believe that structural changes in casein micelles — a kind of milk protein — and new casein-cocoa interactions induced by high-pressure jet processing increased cocoa stability in the chocolate milk,” Harte said. “Because milk protein seemed to be the major component enhancing cocoa stability in samples treated with this method, we conducted a second study to determine the effect of additional milk protein and high-pressure jet processing on the stability of fat-free chocolate milk.”

In findings recently published in the Journal of Dairy Science, the researchers reported that formulations with 4% “micellar casein” processed at 500 megapascals showed no phase separation over a 14-day storage period, stored at 3.89°C. The addition of milk protein together with high-pressure jet processing at 500 megapascals resulted in a higher apparent viscosity that keeps cocoa particles suspended.

Because the use of high-pressure jet technology to improve the dispersion stability of cocoa provides the industry with a processing alternative to produce clean label, yet stable, low-fat chocolate milk, Penn State has applied for a provisional patent on the process and is working with a dairy food manufacturer to develop and scale it up.

High-pressure jet processing of food is a completely new concept, Harte pointed out, and he has been experimenting with the idea for about six years at Penn State. His work on the technology in a pilot plant in the Rodney A. Erickson Food Science Building is unique because it uses an intensifier pump the size of a subcompact car to spray milk through a diamond or sapphire nozzle. The liquid exits the nozzle as a jet of fine droplets that collide with the air, forming an aerosol.

“The equipment that we use for making these chocolate milks is not equipment that you find in the food industry — you would normally find it in an engineering services shop,” Harte said. “This equipment is used for cutting metals. It’s a water jet instrument that is used for cutting tough materials such as marble or stainless steel. We are using it in a completely different application.”

Also contributing to the study were Michelle Tran and Grace Voronin, graduate students in food science; Robert Roberts, professor and head of food science; John Coupland, professor of food science; and Greg Ziegler, professor of food science.
